High pressure filtration standard voltage regulator

Payment Terms:	T/T,L/C,
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: QFRH Series

Production Capacity: 10,000/month

Delivery Date: 2-4 weeks

Operating fluid: Air

Filtering eliment roughness: 20um or 40um

Operating temperature range: 5~80℃

Certification: ISO9001

Means of Transport: Ocean,Land,Air,

Packing: Packing: international stan...

Brand Name: FLEHO

Joint pipe bore: G1/4 G3/8 G1/2 G3/4 G1

Range of adjustustable pressure: 0.15~3.5MPa

Place of Origin: Zhejiang,China (Mainland)

Standard or Nonstandard: Standard

1.Operating temperature range:5~80℃
2.Range of adjustustable pressure:0.15~3.5MPa
3.Joint pipe bore:G1/4 G3/8 G1/2 G3/4 G1

High Pressure Filter & Regulator QFRH Series

1, beforeuse pay attentionto check whetherthe damagedcomponent in thetransport process, andthen install anduse;

2, pay attention to the flow direction of gas (note ","direction) and takeover the tooth typeis correct;

3, pay attention to installation conditions for compliance with technicalrequirements(such as "working pressure","use temperaturerange");

4, please note the use of the medium or the installationenvironment, try to avoid the chlorine, carbon compounds,aromatic compounds and the oxidation of acid and alkali and so on,so as not to damage the cup,cup;

5, regular cleaning or replacement of filters, to the use of oil, the pressure regulating valve should follow the principle from big tosmall;

6, please pay attention to remove dust,do not have to bein charge, outlet ofbellows

TechnicalData
Tybe	QFRH-08	QFRH-10	QFRH-15	QFRH-20	QFRH-25
Operatingfluid	Air
Joint pipebore	G1/4	G3/8	G1/2	G3/4	G1
Filteringeliment roughness	20um or 40um
Qorking ofadjustuble Pressure	0.15~3.5MPa
Max.inputpressure	4MPa
Operatingtemperature range	5~80℃
